Product description
Core Advantages of TW35U:
Extra-Large Range: Digging radius of 5.25m, height of 4.82m.
Ultra-Stable Chassis: 1700mm wide, 3.8-ton weight, longer and wider tracks.
Efficient & Economical: Kubota engine, piston pump hydraulics, fast swing speed.
Large Bucket: 0.11m³ capacity for high efficiency.
Core Selling Points: Wide, Stable, Fast, Economical.
Product Parameters
| Basic Specifications | Operation Weight | 3800KG |
| Engine Brand | Kubota 1703 | |
| Rated Power | 18.2KW | |
| Digging Bucket Capacity | 0.11m³ | |
| Traveling Motor | High and Low Speed-LikCheer | |
| Swing Motor | High and Low Speed-LikCheer | |
| Hydraulic system | Piston Pump | |
| Boom Swing Angel(L/R) | 68/50 | |
| Fuel tank | 40L | |
| Hydraulic oil tank | 41L | |
| Main Dimension | Overall Length | 4945 (mm) |
| Overall Width | 1700(mm) | |
| Overall Height | 2585 (mm) | |
| Track Width | 300 (mm) | |
| Track Length | 2286 (mm) | |
| Performance | Max. Digging Radius | 5251 (mm) |
| Max Digging Depth | 3071 (mm) | |
| Max. Unloading Height | 3382 (mm) | |
| Max. Digging Height | 4815 (mm) | |
| Max. Grade Ability | 35 | |
| Swing Speed | 12R/min | |
| Travel Speed | 4.0/2.3 km/h | |
| Rich Options | Track | |
