Product description
Core Advantages of TW18:
Powerful Performance: 18.1KW engine for greater power.
Strong Digging Capability: Max. digging depth of 2.2m and radius of 3.5m.
Stable Structure: Operating weight of 1400KG with wider 230mm tracks for enhanced stability.
Rich Options: Customizable with high/low speed motors, cab, extendable undercarriage, etc.
Reliable Hydraulics: Gear pump system for easy maintenance.
Core Selling Points: Powerful, deep digging, high stability, customizable.
Product Parameters
| Basic Specifications | Operation Weight | 1400KG |
| Engine Brand | Laidong385 | |
| Rated Power | 18.1KW | |
| Digging Bucket Capacity | 0.04m³ | |
| Traveling Motor | Sanyo | |
| Swing Motor | Sanyo | |
| Hydraulic system | Gear Pump | |
| Boom Swing Angel(L/R) | 55/45 | |
| Fuel tank | 13.5L | |
| Hydraulic oil tank | 18L | |
| Main Dimensions | Overall Length | 3320 (mm) |
| Overall Width | 1100(mm) | |
| Overall Height | 2292 (mm) | |
| Track Width | 230 (mm) | |
| Track Length | 1500 (mm) | |
| Performance | Max. Digging Radius | 3500 (mm) |
| Max Digging Depth | 2200 (mm) | |
| Max. Unloading Height | 1780 (mm) | |
| Max. Digging Height | 2900 (mm) | |
| Max. Grade Ability | 35 | |
| Swing Speed | 10R/min | |
| Travel Speed | 2.1km/h | |
| Rich Options | Engine, High/Low Speed Motor, Cab (with Air Conditioning), Track, Extendable Undercarriage, Variable Double Tandem Plunger Pump, Boom Side Shift. | |
