Product description
Core Advantages of Kubota U20 Excavator:
Compact & Flexible – 2-ton mini body, less than 1m width, passes through narrow spaces
Economical & Practical – 20 hp engine with low fuel consumption and maintenance costs
Easy Operation – Zero-tail swing design enables wall-side operation
Versatile – Compatible with multiple attachments for landscaping/indoor applications
A benchmark in mini excavators, particularly suitable for municipal maintenance and greenhouse operations in space-limited scenarios.
Product Parameters
| Basic Specifications | Operation Weight | 2050KG |
| Engine Brand | Kubota D1105 diesel | |
| Rated Power | 14.7KW | |
| Digging Bucket Capacity | 0.04-0.08m³ | |
| Traveling Motor | High-speed motor + Planetary gear reducer | |
| Swing Motor | High-speed motor + Planetary gear reducer | |
| Hydraulic system | Variable displacement piston pump | |
| Fuel tank | 28L | |
| Hydraulic oil tank | 35L | |
| Main Dimensions | Overall Length | 3540(mm) |
| Overall Width | 980 (mm) | |
| Overall Height | 2350 (mm) | |
| Track Width | 230 (mm) | |
| Track Length | 1420 (mm) | |
| Performance | Max. Digging Radius | 3820 (mm) |
| Max Digging Depth | 2320 (mm) | |
| Max. Unloading Height | 2640 (mm) | |
| Max. Digging Height | 3710 (mm) | |
| Max. Grade Ability | 25 | |
| Swing Speed | 8.5R/min | |
| Travel Speed | 2.2km/h |
