Product description
Superior Power – 532 hp engine delivers powerful performance
Large Bucket Capacity – 4.2-6.0m³ bucket significantly improves work efficiency
Heavy-Duty Design – Reinforced structure adapts to the most extreme working conditions
Intelligent Hydraulics – CLSS system ensures precise control
85-ton ultra-large excavator, specifically designed for extreme heavy-duty applications like large-scale mining and major earthworks projects.
Product Parameters
| Basic Specifications | Operation Weight | 85200KG |
| Engine Brand | Komatsu SAA6D170E-7 | |
| Rated Power | 397KW | |
| Digging Bucket Capacity | 4.2-6.0m³ | |
| Traveling Motor | High-speed motor + Planetary gear reducer | |
| Swing Motor | High-speed motor + Planetary gear reducer | |
| Hydraulic system | Variable displacement piston pump | |
| Fuel tank | 1650L | |
| Hydraulic oil tank | 820L | |
| Main Dimensions | Overall Length | 15220(mm) |
| Overall Width | 3650 (mm) | |
| Overall Height | 4680 (mm) | |
| Track Width | 800 (mm) | |
| Track Length | 8150 (mm) | |
| Performance | Max. Digging Radius | 15290 (mm) |
| Max Digging Depth | 10120 (mm) | |
| Max. Unloading Height | 10250 (mm) | |
| Max. Digging Height | 13320 (mm) | |
| Max. Grade Ability | 35 | |
| Swing Speed | 8.8R/min | |
| Travel Speed | 4.2km/h |
