Product description
Core Advantages of Komatsu PC400-7 Excavator:
Superior Power – 385 hp engine with strong performance
Intelligent Hydraulics – CLSS system enables precise control
Robust Durability – Reinforced structure for heavy-duty applications
High Efficiency – Optimized fuel consumption
41-ton large excavator, particularly suitable for heavy-duty operations like mining and large earthworks.
Product Parameters
| Basic Specifications | Operation Weight | 41200KG |
| Engine Brand | Komatsu SAA6D140E-3 | |
| Rated Power | 287KW | |
| Digging Bucket Capacity | 1.9-2.8m³ | |
| Traveling Motor | High-speed motor + Planetary gear reducer | |
| Swing Motor | High-speed motor + Planetary gear reducer | |
| Hydraulic system | Variable displacement piston pump | |
| Fuel tank | 900L | |
| Hydraulic oil tank | 450L | |
| Main Dimensions | Overall Length | 12350(mm) |
| Overall Width | 3320(mm) | |
| Overall Height | 3720(mm) | |
| Track Width | 600 (mm) | |
| Track Length | 5980 (mm) | |
| Performance | Max. Digging Radius | 12420 (mm) |
| Max Digging Depth | 8520 (mm) | |
| Max. Unloading Height | 8650 (mm) | |
| Max. Digging Height | 11680 (mm) | |
| Max. Grade Ability | 35 | |
| Swing Speed | 10.8R/min | |
| Travel Speed | 5.0km/h |
