Product description
Core Advantages of Komatsu PC375LC-11M0 Excavator:
Superior Power – 306 hp engine with strong performance
Intelligent Hydraulics – CLSS system enables precise control
Long Track Design – Reduced ground pressure for better stability
High Efficiency – Optimized fuel consumption
38-ton long-track excavator, particularly suitable for soft ground and mining applications.
Product Parameters
| Basic Specifications | Operation Weight | 38500KG |
| Engine Brand | Komatsu SAA6D140E-5 | |
| Rated Power | 228KW | |
| Digging Bucket Capacity | 1.8-2.6m³ | |
| Traveling Motor | High-speed motor + Planetary gear reducer | |
| Swing Motor | High-speed motor + Planetary gear reducer | |
| Hydraulic system | Variable displacement piston pump | |
| Fuel tank | 820L | |
| Hydraulic oil tank | 400L | |
| Main Dimensions | Overall Length | 12020(mm) |
| Overall Width | 3250(mm) | |
| Overall Height | 3620(mm) | |
| Track Width | 600 (mm) | |
| Track Length | 5780 (mm) | |
| Performance | Max. Digging Radius | 12090 (mm) |
| Max Digging Depth | 8250(mm) | |
| Max. Unloading Height | 8380(mm) | |
| Max. Digging Height | 11320 (mm) | |
| Max. Grade Ability | 35 | |
| Swing Speed | 11.2R/min | |
| Travel Speed | 5.2km/h |
