Product description
Three Core Advantages of the Caterpillar 320B Excavator:
Powerful Performance – 103kW turbocharged engine combined with an intelligent hydraulic system delivers outstanding efficiency in heavy-duty operations.
Robust Durability – Reinforced structural design of key components ensures long service life and low failure rates.
Operator-Friendly – Ergonomic cab and intelligent temperature control system provide comfort during long working hours.
This medium-sized excavator offers an ideal balance of productivity, durability, and operator comfort, making it a cost-effective choice for a wide range of engineering projects.
Product Parameters
| Basic Specifications | Operation Weight | 21300KG |
| Engine Brand | Cat 3066T | |
| Rated Power | 103KW | |
| Digging Bucket Capacity | 0.8-1.5m³ | |
| Traveling Motor | High-speed motor + Planetary gear reducer | |
| Swing Motor | High-speed motor + Planetary gear reducer | |
| Hydraulic system | Variable displacement piston pump | |
| Fuel tank | 400L | |
| Hydraulic oil tank | 240L | |
| Main Dimensions | Overall Length | 9755(mm) |
| Overall Width | 2800(mm) | |
| Overall Height | 3100(mm) | |
| Track Width | 600 (mm) | |
| Track Length | 4500 (mm) | |
| Performance | Max. Digging Radius | 9890 (mm) |
| Max Digging Depth | 6690 (mm) | |
| Max. Unloading Height | 6680 (mm) | |
| Max. Digging Height | 9530 (mm) | |
| Max. Grade Ability | 35 | |
| Swing Speed | 11.5R/min | |
| Travel Speed | 5.5km/h |
